Pilot release
Sketches to CAD, without the manual redraw.
Upload a DXF and your sketch scans. When processing finishes, download an industry-standard DWG and a print-ready PDF — in under 15 minutes.
- <15min
- per drawing
- DWG+PDF
- outputs per run
- Pilot
- early access
Process
Three steps, one deliverable
Upload, wait, download.
01
Upload DXF + sketches
Drop your base DXF file for structural context and one or more scanned sketch images.
02
Automated processing
Our engine vectorises strokes, aligns geometry, and generates fully layered CAD data.
03
Download DWG & PDF
Receive an industry-standard DWG file and a print-ready PDF plot, ready to hand off.
Capabilities
Built for construction workflows
Every output follows the conventions your team already uses.
Sketch alignment
Pen strokes and annotations are registered against the DXF coordinate space automatically.
DWG layer generation
Output respects standard layer conventions — walls, openings, dimensions, and annotations.
Print-ready PDF
A formatted plot sheet is generated from the DWG, fit for client review or site markup.
Early access
Start your first conversion
Pilot builds are free. Join the engineers already using Constructors.
